Click to enlarge5-Way Crosses

Conflat 5 WAY CROSS
• 304 Stainless
• Conflat Flange (CF)
• Five Way Crosses
OD Polish



Ultra High Vacuum (UHV) FIVE-WAY Cross Fitting

Conflat Flange (CF) High and UHV Vacuum Fittings

1.33" OD Conflat

0.75" Tube OD

(6 Bolt Holes)

2.12" OD Conflat

1.00" Tube OD

(4 Bolt Holes)

2.75" OD Conflat

1.50" Tube OD

(6 Bolt Holes)

3.38" OD Conflat

2.00" Tube OD

(8 Bolt Holes)

4.50" OD Conflat

2.50" Tube OD

(8 Bolt Holes)

4.62" OD Conflat

3.00" Tube OD

(10 Bolt Holes)

6.00" OD Conflat

4.00" Tube OD

(16 Bolt Holes)

8.00" OD Conflat

6.00" Tube OD

(20 Bolt Holes)





1.33" OD Conflat Flange
Five-Way Cross
(133-075-5X)


Price: $320.15
Sale: $241.00
1.33" OD Conflat Flange
Five-Way Cross
(133-5X-VE)


Vacuum Essential
$274.00
2.12" OD Conflat Flange
Five-Way Cross
(212-100-5X)


Price: $552.50
Sale: $259.00
2.12" OD Conflat Flange
Five-Way Cross
(212-5X-VE)


Vacuum Essential
$301.00
2.75" OD Conflat Flange
Five-Way Cross
(275-150-5X)


Price: $478.24
Sale: $286.00
2.75" OD Conflat Flange
Five-Way Cross
(275-5X-VE)


Vacuum Essential
$333.00
3.38" OD Conflat Flange
Five-Way Cross
(338-200-5X)


Price: $1,133.50
Sale: $509.00
3.38" OD Conflat Flange
Five-Way Cross
(338-5X-VE)


Vacuum Essential
$579.00
4.50" OD Conflat Flange
Five-Way Cross
(450-250-5X)


Price: $1,367.00
Sale: $687.00
4.50" OD Conflat Flange
Five-Way Cross
(450-5X-VE)


Vacuum Essential
$802.00
4.62" OD Conflat Flange
Five-Way Cross
(462-300-5X)


Price: $1,742.50
Sale: $854.00
4.62" OD Conflat Flange
Five-Way Cross
(462-5X-VE)


Vacuum Essential
$938.00
6.00" OD Conflat Flange
Five-Way Cross
(600-400-5X)


Price: $2,054.00
Sale: $1,088.00
6.00" OD Conflat Flange
Five-Way Cross
(600-5X-VE)


Vacuum Essential
$1,227.00
8.00" OD Conflat Flange
Five-Way Cross
(800-600-5X)


Price: $3,670.00
Sale: $1,968.00
8.00" OD Conflat Flange
Five-Way Cross
(800-5X-VE)


Vacuum Essential
$2,136.00
5-Way Crosses

Price On Request Items



**Vacuum Essentials Include**
• 5-WAY CROSS
• 5-Bolt Kits (BK Series)
• 10-Copper Gaskets (CG Series)

Contact LDS Vacuum with any questions:
Phone (407)862-4643 via Fax (407)862-8723 or
info@ldsvacuum.com

LDS Vacuum Products is a 100% woman owned company and
certified Woman Owned Small Business (WOSB)
