NW16 & NW10 Clamping Ring
PACK OF 10

NW16-CHK-PK10
NW16 & NW10 (KF16, KF10) Horseshoe Clamp
Spring Clamp with Blue Knob
NW, KF, QF Clamping Ring
PACK OF 10

• 304 Stainless
• NW16 & NW10 Series (KF, QF)
• High Vacuum Clamps (Klamp)

NW (KF) High Vacuum Hardware
• Fits KF, NW, QF Series Flanges & Fittings
• Fits Kwik-Flange, Quick Flanges & Fittings
• Quick Clamp

NW10 Flange OD: Ø1.18"
• NW10 Tube OD: 0.50" (Typical)
• NW10 Centering Ring Counter Bore: 0.48"

NW10 High Vacuum Flange Equivalents
KF10, KF-10, K050, NW-10, QF10, ISO-QF, Klamp


NW16 Flange OD: Ø1.18"
• NW16 Tube OD: 0.75" (Typical)
• NW16 Centering Ring Counter Bore: 0.68"

NW16 High Vacuum Flange Equivalents
KF16, KF-16, K075, NW-16, QF16, ISO-QF
NW16-075-CHK NW16-075-CHK-PK10 P107653 C10512401


Horseshoe Spring Clamp with Blue Plastic Knob
Fits: NW16 & NW10
NW16-CHK-PK10

NW16-CHK-PK10$63.00

Click to enlarge
Click to enlarge
All NW16 Hardware


All NW10 Hardware


Click to enlarge
Click to enlarge
Need Just One?


NW10 & NW16 Clamps (All Types)
