Click to enlarge3.38" OD Conflat Flexible Metal Hose
48" Overall Length
Vacuum Essential

338-MH48M-VE
3.38" OD Conflat Flange (CF) Series
48" OAL CF Flexible Metal Hose (Bellows)
Vacuum Essential

• 0.012" Wall Thickness (Medium)
• 1 Rotatable Conflat Flange
• 304 Stainless Steel
• Hydraulically Formed Ultra-High Vacuum (UHV) Bellows

3.38" OD CF Conflat Flange
• Ø2" Hose ID
• 8 Clearance (Thru) Holes
• 0.332" Bolt Hole Diameter

3-3/8" OD Conflat Flange (CF) Equivalents:
• 338CF, CF338, DN50CF, NW50CF, 3.375" CFF

Images for Reference Only
Compare to: 338-MH48-M-VE, 338-MH48-T-VE


3.38" Flexible Metal Hose 48" OAL
(338-MH48M-VE)

338-MH48M-VE$595.00

Click to enlarge
Click to enlarge
3.38" OD Conflat Series Hardware


3.38" Metal Hose
Additional Sizes




**This Vacuum Essential Includes**
3.38" Conflat Flexible Metal Hose (Bellows)
• 2-Bolt Kits (338-BK Series)
• 10-Copper Gaskets (338-CG Series)
